| Current Revision | R2C |
| Status | discontinued |
| Variants | DIMM-EMEV2-256RAM-512FLASH; DIMM-EMEV2-512RAM-512FLASH |
| Temperature Range | -10°C – 70°C |
| Size (WxDxH) | 67,6mm x 50mm x 10mm |
| Power Consumption | max. 350mA |
| Special Functions | • CPU performance: 2x 533 MHz - 2600 DMIPS • Co-Processor: 2x ARM NEON, VFPU • Video processing (Hardware accelerated): H.264 decode at 1080p30 • 2D (Hardware accelerated) • 3D (Hardware accelerated): openGL ES 2.0 & 1.x (14.7 Mpol/s, 500 Mpix/s, shader: 1.6 GFLOPS) H.264 decode at 1080p30 |
| Supported Carrierboards | • Cadun • Lothron • Tarion • Verno |
Functions
Memory
| DDR2-SDRAM | 256 – 512 MB | |
|---|---|---|
| NAND-Flash | 2096 – 8192 MB | |
Multimedia
| Camera Interface 1 | 1 x |
|---|---|
| SSI Interface for Audio Codec | 1 x |
| Video Output Interface für NTSC Encoder | 1 x |
| Touch interface (resistive, 4-wire) | 1 x |
| LCD Interface (RGB) | 1 x |
Connectivity
| CAN LVTTL | 1 x |
|---|---|
| Digital GPIO | 8 x |
| I²C Interface | 1 x |
| MMC/SDC Interface | 2 x |
| SPI Interface | 1 x |
| UART LVTTL | 3 x |
| UART RS232 | 1 x |
| USB Device 2.0 high speed | 1 x |
| USB Host 2.0 high speed | 1 x |
| CPU-Bus | 1 x |
Miscellaneous
| RTC (battery buffered) | 1 x |
|---|
Software
| Name | Distribution | Version | Codename | |
|---|---|---|---|---|
| Android | 2.3.4 | Gingerbread | ||
| Linux | emLinux | |||
| U-Boot | 2010.06 |
Supported operating systems
• Android Gingerbread 2.3.4 v20120502
• Linux emLinux v20
